Materials for Additive Manufacturing and 3D printing processes

Materials

SLS – Selective Laser Sintering

SLS Materials

Prosilas is one of the leading companies in the use of SLS technology.



Prosilas’ strong experience in these technologies allows it to constantly research and test new materials to enable new applications.

Polyammide PA12

It is the most used polymer in laser sintering process and it is also the base of almost all the other materials.

It has an excellent mechanic and thermic performance, for this reason it is suitable to produce functional parts. It is biocompatible and FDA certified (food use).

Alumide / PA12 + Aluminum

Alumide is a polyamide PA12 with aluminium charge. It adds to the polyamide more stiffness.

Thanks to aluminium, heat can dissipate easily and it guarantees a better result for the following CNC mechanic productions.

PA12 + Carbon Fiber

It is a polyamide PA12 charged with carbon fibers.

It is a high-mechanic performance material, it is very
demanded for its high resistance that allows it to be used for stressed components in the aerospace,
motorsport and automotive.

It has electric capacities thanks to the presence of carbon fibers.

PA12 + Glass Spheres

It is a polyamide PA12 charged with micro spheres of glass. Thanks to the glass charge in the polyamide, it is more rigid and keeps the same properties of PA12.

Parts produced with this material have a better result for the following CNC machining and an excellent resistance to abrasions.

TPU

TPU (thermoplastic polyurethane) is a material with an excellent elasticity and elongation properties, this guarantees flexibility, durability and resistance to lacerations and abrasions.

Its use is recommended for tubes, gaskets, technical clothing and footwear, and for all those applications that need a material able to be flexible.

PA12 Flame Retardant

It is a polyamide with self-extinguish capacity (halogen free). V-0 for thickness bigger than 2 mm.

It is JAR25 certified for aviation and UL94 certified for the realisation of components applied in electric and electronic systems where self-extinguish characteristics are required.

Polyamide PA6 MF (Mineral Filled)

PA6 MF is a polyamide mineral reinforced that offers mechanic performances and high-temperature
resistance. A stronger material than other polyamides for SLS technology.

The mineral reinforcement is in particle in order to have very homogenous mechanical properties.

This material is recommended for the automotive, mechanics and for every application that requires high-performances.

Polypropylene PP

It is a polymer specifically developed for 3D SLS printing as alternative to polyamide.

Polypropylene, differently from polyamides, offers an excellent plasticity, elongation and great capacity of shock absorption, low moisture absorption and durability.

Polyammide PA12

It is the most used polymer in laser sintering process and it is also the base of  all the other sls materials.

It has an excellent mechanic and thermic performance, for this reason it is suitable to produce functional parts. It is biocompatible and FDA certified (food use).

Alumide / PA12 + Aluminum

Alumide is a polyamide PA12 with aluminium charge. It adds to the polyamide more stiffness.

Thanks to
aluminium, heat can dissipate easily and it guarantees a better result for the following CNC mechanic productions.

PA12 + Carbon fiber

It is a polyamide PA12 charged with carbon fibers. It is a high-mechanic performance material, it is very
demanded for its high resistance that allows it to be used for stressed components in the aerospace,
motorsport and automotive. It has electric capacities thanks to the presence of carbon fibers.

PA12 + Glass Spheres

It is a polyamide PA12 charged with micro spheres of glass. Thanks to the glass charge in the polyamide, it is more rigid and keeps the same properties of PA12. Parts produced with this material have a better result for the following CNC machining and an excellent resistance to abrasions.



TPU

TPU (thermoplastic polyurethane) is a material with an excellent elasticity and elongation properties, this guarantees flexibility, durability and resistance to lacerations and abrasions.

Its use is recommended for
tubes, gaskets, technical clothing and footwear, and for all those applications that need a material able to be flexible.



PA12 Flame retardant

It is a polyamide with self-extinguish capacity (halogen free). V-0 for thickness bigger than 2 mm.

It is JAR25 certified for aviation and UL94 certified for the realisation of components applied in electric and electronic systems where self-extinguish characteristics are required.

Polyamide PA6 MF (Mineral Filled)

PA6 MF is a polyamide mineral reinforced that offers mechanic performances and high-temperature
resistance. A stronger material than other polyamides for SLS technology.

The mineral reinforcement is in particle in order to have very homogenous mechanical properties. Recommended for the automotive, mechanics.

Polypropylene

It is a polymer specifically developed for 3D SLS printing as alternative to polyamide.

Polypropylene, differently from polyamides, offers an excellent plasticity, elongation and great capacity of shock
absorption, low moisture absorption and durability.

.

SLA – STEREOLITOGRAPHY

SLA Materials

Prosilas has SLA systems that allow you to produce prototypes with extreme precision and high detail resolution.



Thanks to these stereolithography systems it is possible to create complex geometries, to evaluate design strategies and accelerate R&D processes.

materiali-stereolitografia-trasparente

TRANSPARENT RESIN

The transparent resin used in stereolithography allows to create detailed prototypes with high surface quality.
Ideal applications: automotive lights, cover led, guiding lights, displays etc…

Through the surface finishes it is possible a total transparency or a transparent opaque finish or even an opal effect.

materiali-stereolitografia-bianca

ABS-like resin

Simil-ABS resin is a multipurpose resin with a good cost-quality ratio.

It is the right material when you need a prototype as close as possible to the final object.

HIGH TEMPERATURE RESISTANT RESIN

It is the right material to produce parts with high stiffness, high surface quality and that must withstand  high temperatures.

With this resin it is possible to produce prototype moulds for injection moulding (ex. through a babyplast press)

materiali_stampa3d_stereolitografia_similgomma_a

RUBBER - LIKE RESIN

It is a black, flexible material that replicates the characteristics of common rubbers for injection moulding.

TRANSPARENT RESIN

The transparent resin used in stereolithography allows to create detailed prototypes with high surface quality.
Ideal applications: automotive lights, cover led, guiding lights, displays etc…

Through the surface finishes it is possible a total transparency or a transparent opaque finish or even an opal effect.

Data sheet >

ABS - LIKE RESIN

Simil-ABS resin is a multipurpose resin with a good cost-quality ratio.

It is the right material when you need a prototype as close as possible to the final object.

Data Sheet >

HIGH TEMPERATURE RESISTANT RESIN

It is the right material to produce parts with high stiffness, high surface quality and that must withstand  high temperatures.

With this resin it is possible to produce prototype moulds for injection moulding (ex. through a babyplast press)

Data Sheet >

RUBBER - LIKE RESIN

It is a black, flexible material that replicates the characteristics of common rubbers for injection moulding.

Data Sheet >

dmls – Direct metal laser sinteting

DMLS Materials

Prosilas uses the best metal powder beds systems, this allows the production of functional parts and prototypes.

DMLS and SLM technologies and materials guarantee the best 3D printing performance for metals.

AlSi10Mg

AlSi10Mg it is an aluminium alloy that combines good mechanical strength, thermal properties, low weight.
Applications include frames, ducts, engine components, tools and production moulds.

Data Sheet >

Stainless Steel AISI316L

A steel alloy rich in chromium, nickel and molybdenum, it is a sturdy material that also has excellent
corrosion resistance and can be easily worked with a machine tool and finished.

Ideal in the most varied applications of the industrial world.

Data Sheet >

Titanium Ti6Al4v

Ti6Al4v titanium has exceptional mechanical properties and corrosion resistance, as well as having a low
specific weight and remarkable biocompatibility features.  Ideal for aerospace, motorsport and biomedical.

Data Sheet >

Maragin Steel

Maraging steel, thanks to the presence of cobalt and nickel, is a special steel with excellent characteristics
of hardness but at the same time of good toughness with an elastic behavior almost to the breaking load.

Data Sheet >

materiali dmls

AlSi10Mg

AlSi10Mg it is an aluminium alloy that combines good mechanical strength, thermal properties, low weight.
Applications include frames, ducts, engine components, tools and production moulds.

Data Sheet >

materiali dmls

Stainless Steel AISI316L

A steel alloy rich in chromium, nickel and molybdenum, it is a sturdy material that also has excellent corrosion resistance and can be easily worked with a machine tool and finished.

Data Sheet >

materiali dmls

Maraging Steel

Maraging steel, thanks to the presence of cobalt and nickel, is a special steel with excellent characteristics of hardness but at the same time of good toughness with an elastic behaviour almost to the breaking load.

Data Sheet >

materiali dmls

Ti6Al4v Titanium

Ti6Al4v titanium has exceptional mechanical properties and corrosion resistance, as well as having a low specific weight and remarkable biocompatibility features.  Ideal for aerospace, motorsport and biomedical.

Data Sheet >

FDM – Fused deposition modeling

Materiali FDM

Prosilas has the best FDM (Fused Deposition Modeling) on ​​the market for the creation of aesthetic prototypes and functional parts.

Thanks to FDM systems, 3D parts can be printed in technical polymers for engineering use.

ULTEM 1010

This resin is the most resistant FDM thermoplastic.

Thanks to its high resistance and thermal stability characteristics, it is able to support autoclave operations associated both to sterilization and to the creation of composite artifacts.

Data sheet >

ULTEM 9085

This resin is a light material, high resistant and completely auto-extinguishing.

It is FST (Flame, Smoke,Toxicity) certified. Applications: aeronautic, motorsport, aerospace (FAR 25.853).

Data sheet >

ABS M30

This material is ideal for conceptual models and parts with a moderate level of requirements, for example
functional prototypes, masks, brackets, production instruments and production parts.

Data Sheet >

ABS-POLYCARBONATE

The PC-ABS is a high-impact, technic thermoplastic ideal for functional prototyping, instruments construction and low-volume production. It has the best features of two FDM materials, the strength and thermic resistance of polycarbonate and the flexibility of ABS.

Data sheet >

POLYCARBONATE

Fast making for high resistance parts. This material offers precision, durability and stability and it allows to
produce resistant parts able to support functional tests and templates.

It also allows engineers and designers to combine the speed and agility of 3D printing with the reliability of the most popular industrial thermoplastic.

Data sheet >

ASA

Outdoors manufacturing parts take advantage of the strength, colour choice and UV resistance of the ASA
material.

ASA eases of use makes it an exceptional choice for iterative projects, from housings and
supports for electrical equipment to sporting goods and automotive prototypes.

Data sheet >

ULTEM 1010

This resin is the most resistant FDM thermoplastic.

Thanks to its high resistance and thermal stability characteristics, it is able to support autoclave operations associated both to sterilization and to the creation of composite artifacts.

Data sheet >

ULTEM 9085

This resin is a light material, high resistant and completely auto-extinguishing.

It is FST (Flame, Smoke,Toxicity) certified. Applications: aeronautic, motorsport, aerospace (FAR 25.853).

Data sheet >

ABS M30

This material is ideal for conceptual models and parts with a moderate level of requirements, for example
functional prototypes, masks, brackets, production instruments and production parts.

Data sheet >

ABS-POLYCARBONATE

The PC-ABS is a high-impact, technic thermoplastic ideal for functional prototyping, instruments construction and low-volume production. It has the best features of two FDM materials, the strength and thermic resistance of polycarbonate and the flexibility of ABS.

Data sheet >

POLYCARBONATE

Fast making for high resistance parts. This material offers precision, durability and stability and it allows to
produce resistant parts able to support functional tests and templates.

It also allows engineers and designers to combine the speed and agility of 3D printing with the reliability of the most popular industrial thermoplastic.

Data sheet >

ASA

Outdoors manufacturing parts take advantage of the strength, colour choice and UV resistance of the ASA
material.

ASA eases of use makes it an exceptional choice for iterative projects, from housings and supports for electrical equipment to sporting goods and automotive prototypes.

Data sheet >
